Manual Edge Cutting Machine

Features: 1.The cutters position can be easily adjusted in both vertical and horizontal directions according to the practical measurement of workpiece. Therefore they are applicable to cutting slabs of varied specifications. 2.The blade can be tilted up to 45°for chamfering. 3. The great strength and high efficiency of the machine makes it possible to turn out slabs with accurate dimension and specification, straight and smooth edge. Note: 1) The main motor can adopt 15kw as per customers requirement. 2) The max. processing width can be 1200mm. (Made to order ) 3) The slicing can adopt dynamoelectric form. (Made to order) 4) The disc diameter can be 600mm, 700mm, 800mm. (Made to order) 5) It can act as a slot cutting machine 6) The horizontal cutter can be added. The technical data of SQJ series are as follows: NameSQJ-22LSSQJ-22YLSSQJ-28LSSQJ-28YLSSQJ-30LSMax.processing lengthmm20002000260026002800Max.processing widthmm12001200120012001200Blade diametermm400400400400400Main motor powerkw1515151515Guide rail typesteel railoil-immersed sealingsteel railoil-immersed sealingsteel railDimensions (LxWxH)mm4000x1960 x2100 4300x1960 x2100 5000x1960 x2100 5300x1960 x2100 5600x1960 x2100 Water consumptioncub.m/h22222Weightkg28002800300030003100
